1, the solution to the market roll sticker there is no way to do real-time printing and labeling function of the pain points
--Corresponding to the problem of labeling, the fastest labeling speed can reach 50 sheets / minute!
2、High expandability
3, in the roll labeling mode can be realized under the label and the labeled items one to one correspondence
4, the speed than the printing and labeling of the traditional pressure paste speed faster
5, compared with the traditional roll labeling equipment, in the replacement of different sizes of labels, debugging more easily
| Labeling method: | Roll labeling |
| Labeling arm model: | P54G |
| Labeling speed (optional high-speed cylinder): | 50 sheets / min |
| Labeling stroke: | 100mm |
| Labeling precision: | ±1mm |
| Product size (body + labeling arm): | 778.4*453.5*562mm |
| Product weight: | 56KG |
| Printer Brand: | ZEBRA, TSC |
| Print resolution: | 203dpi, 300dpi, 600dpi |
| Printing label material: | coated paper, thermal paper, PE composite film, etc. |
| Applicable label size: | W:13-1 68mm, H: 10-300mm |
| Label roll size: | inner diameter 7 6mm, outer diameter 300mm |
| Working voltage: | 100-220V |
| Working air pressure: | 0.4-0.6Mpa |
| Print data transmission interface: | USB, Internet |
| Control interface: | 2PIN RS485, 4PIN active interface, 9PIN IO point |
| Warranty: | 1 year |
